UMARO sc14 1982
- Condizione: usato
- pubblicato: 06/10/2025
- 25IND3810
Dati tecnici
- Condizione: usato
- Anno: 1982
Descrizione
Manufacturer: TITAN UMARO
Model:
SC 14 CC
Specifications
Main Technical Characteristics: -Max. turning diameter 1400 mm -Faceplate diameter 1200 mm -Max. height of workpiece under traverse 100 ...
Manufacturer: TITAN UMARO
Model:
SC 14 CC
Specifications
Main Technical Characteristics: -Max. turning diameter 1400 mm -Faceplate diameter 1200 mm -Max. height of workpiece under traverse 1000 mm -Max. weight of workpiece 6000 kg -Main motor power 55 kW -Table speed range 5 - 250 rpm -Working and rapid feed range 0,05 - 5 mm/rot -Max. travel of cross rail 800 mm -Max. travel for right support slide 760 mm -Max. travel of side head slide 650 mm -Weight 16100 kg -Overall dimensions (LxBxH) 4060x4450x3900 mm
