DOOSAN Puma 3100ULY 2014
- Condizione: usato
- pubblicato: 06/10/2025
- 25IND41775
Dati tecnici
- Condizione: usato
- Anno: 2014
Descrizione
Manufacturer Doosan
Model Puma 3100ULY
Year 2013
Condition Used
Stock Number 65
CNC FANUC i Series 31 i A
Swing over bed 850mm
Swing over saddle 670mm
Max. Turning Diameter 420mm
Max. Turning ...
Manufacturer Doosan
Model Puma 3100ULY
Year 2013
Condition Used
Stock Number 65
CNC FANUC i Series 31 i A
Swing over bed 850mm
Swing over saddle 670mm
Max. Turning Diameter 420mm
Max. Turning length 3.125mm
Axis travels X 210mm Y +/-60mm Z 3.125mm
Chuck diameter (*)400mm
bar capacity 102mm
Spindle head 2.800RPM - 22Kw
Turret 12 stations
Rotary tools 7,5kw 5.000rpm
C axis Continuous.Indexing 0.001
Tailstock Travel 3,135mm
Steady Rest SMW AUTOBLOK SLU-X-4-ZS
Hydraulic Chuck Yes
Automatic Tool Setter Yes
Chip Conveyor Yes
Tool Holders Included 8 Tool holders (4 I-4 O) and 4 Rotary (2 Straight-2 Angle)
Machine condition Excellent Condition.Under power for inspection.
