RAMBAUDI RamSpeed B20L
- Condizione: usato
- pubblicato: 06/10/2025
- 25IND5114
Dati tecnici
- Condizione: usato
- Anno: non definito
Descrizione
Gantry High Speed Machining Center
Operating hours 23.000
Inspection under power possible by prior arrangement .
CNC control Heidenhain TNC530 (retrofit for € 75.000,-
in the year 2008)
5 axe ...
Gantry High Speed Machining Center
Operating hours 23.000
Inspection under power possible by prior arrangement .
CNC control Heidenhain TNC530 (retrofit for € 75.000,-
in the year 2008)
5 axes
travels
X = 2.000mm
Y = 1.500mm
Z = 1.000mm
A = + / - 110 deg
C = +150 deg / -200 deg
Fork milling head 1 ° indexing in A and C
Spindle taper HSK A63
Spindle speed 24.000 rpm
Spindle power 30 kW
Table size 2.500 x 1.700mm
Table load 10,000 kg
T-slots 22mm / 150 mm distance
Feed max . 16.000 mm/min.
Rapid max. 16.00 0mm/min.
Tool magazine 24 places
Additional table 1.100 x 1.100 x 340 mm
T-slots 14 + 22mm / 100mm distance
Accessories:
Two chip conveyor (left / right of the table )
Cooling unit for cooling spindle
Electronic handwheel
Tool measurement " Blum " (laser )
Probe (M & H)
Minimum quantity lubrication
Coolant system externally via nozzles with filter band
Blowing air externally via nozzles
Chip flushing gun
KinematicsOpt software ( TCP calibration )
Original price in the year 2000 € 525,000 -
