VMC1206 2016
- Condizione: usato
- pubblicato: 06/10/2025
- 25IND9396
Dati tecnici
- Condizione: usato
- Anno: 2016
Descrizione
Technical Specification
Standard Feature
Travel（X/Y/Z）1050/600/600 mm
Spindle nose to machining table 150~750mm;
Worktable（Length× Width）1250×600 mm;
Max. load capacity 1000kg
T slo ...
Technical Specification
Standard Feature
Travel（X/Y/Z）1050/600/600 mm
Spindle nose to machining table 150~750mm;
Worktable（Length× Width）1250×600 mm;
Max. load capacity 1000kg
T slot NO.*width*distance 5*18*100
Spindle speed 10~8000 rpm
Spindle motor 11/15 kW, Spindle taper BT40;
Rapid feed speed(X/Y/Z-axis) 36/36/24m/min
Cutting feed speed 1~10000 mm/min
Tool magazine capacity 24T
Max diameter/length/weight of tool 80mm/300mm/8kg
Max tool dia. (without adjacent tool) 150mm
Tool change way random
Tool change time 1.8s
Positioning accuracy (X/Y/Z-axis):0.010/0.010/0.010 mm
Repeatability (X/Y/Z-axis):0.006/0.006/0.006mm
Max drilling diameter Æ45
Max tapping screw diameter M24
Milling capability 250 cm³/min
Power capacity:35 KV A,
Air pressure 6-8 bar
Cooling tank capacity:350L
Machine Dimension (l ×w ×h): 4600×2490×3200mm
Net weight:8000kg
a) FANUC 0i-MD NC system (Fanuc-Japan);
b).Hand held operating unit (China);
c).Disc-type tool magazine 24 tools (SY-Taiwan);
d).X/Y/Z linear rails
e).Chain-type chip conveyor;
f). Electric cabinet air-conditioner ;
g).Automatic lubricating system;
h). Tri-color lamp;
i). Air through spindle;
j). Air curtain protection;
k). Air gun;
l). Work lamp;
m).Random technique document &accessories
